DC-8 GHz, 1-60 dB, 2 Watts, 2.2-5, Bidirectional - SRFS-08XXZC2
The SRFS-08XXZC2 is a high-performance bidirectional RF attenuator designed for reliable signal control across a DC to 8 GHz frequency range. It provides adjustable attenuation from 1 to 60 dB with a power handling capability of 2 Watts, making it suitable for demanding RF applications. Featuring a 2.2-5 interface, this attenuator offers excellent connectivity, stable electrical performance, and accurate signal reduction. It is ideal for telecommunications, RF testing, measurement systems, laboratory equipment, wireless communication, and network infrastructure applications where precise attenuation and dependable bidirectional signal performance are required.
Electrical Specifications
| Impedance | 50 ohm | ||||
| Frequency Range | DC-6 GHz | ||||
| VSWR | 1.25 max | ||||
| Input Avg Power | 2W @ 25°C ambient, derating linearly to 0.2W at 100°C | ||||
| Peak Power | 200W (5 micro-sec pulse width, 0.5% duty cycle) | ||||
| Direction | Bidirectional, 2.2-5 female to 2.2-5 male (other configurations available) | ||||
| Attenuation (dB) | 1-6 | 7-10 | 11-20 | 21-30 | 40-60 |
| Accuracy (dB) | ±0.5 | ±0.5 | ±0.6 | ±0.8 | ±0.9 |
Mechanical Specifications
| Connector Body | Ternary alloy plated brass |
| Heat Sink | N/A |
| Center Contact | Gold plated beryllium copper/brass |
| Net Weight | Approx 35 g |
Environmental Specifications
| Operating Temperature | -55°C to 100°C |
| Storage Temperature | -55°C to 125°C |
| RoHS | Compliant |
| Temperature Coefficient | <0.0004 dB/dB/°C |
